The Eaton PDG23G0015TFFJ is a 3 Pole thermal magnetic molded case circuit breaker with a current rating of 15 Amps and a voltage rating of 600VAC 250VDC. It has an interrupting rating of 35kAIC at 480VAC. The PDG23G0015TFFJ has a panel mounting type and includes LI - long time and instantaneous functions.
Price range: $449.99 through $498.32
| Brand | Eaton |
| Series | PDG |
| Amperage | 15 |
| Voltage | 600VAC, 250VDC |
| Poles | 3 |
| Phase | 3 |
| Mounting Type | Panel |
| Approval | UL, CSA, IEC, CCC, CE |
| Interrupting Rating | 35kAIC at 480VAC |
| Connection Type | Feed-Thru |
| Protection | Thermal Magnetic |
| Functions | LI – Long Time and Instantaneous |
| Terminal Connection | Standard Line and Load |
| Standards | RoHS |
| Circuit Breaker Type | PD2 Global |
| Mpn | PDG23G0015TFFJ |
No reviews found.
