Siemens / ITE Bolt-On Circuit Breaker has a 2 pole 60 ampere bolt on connection type with 120V shunt trip (LI) Long-Time and Instantaneous trip functions and load side lug terminals thermal magnetic molded case circuit breakers.
$141.99
| Type | Molded Case- Thermal and Fixed Magnetic- Branch- Common Trip |
| Voltage Rating | 120/240 Volt AC at 50/60 Hertz (UL) |
| Current Rating | 60 Ampere at 40 Deg C |
| Number of Poles | 2 |
| Interrupting Rating | 10 Kiloamp at 120/240 Volt AC (UL) |
| Installation | Bolt-ON |
| Application | Lighting- Distribution |
| Used On | P1/P2/P3/P4/P5 Panelboard |
| Approval | UL 489- CSA C22.2 |
| Brand Name | SPEEDFAXâ„¢ |
| Additional Information | Frame Type BL- Terminal Type Load Lug- Overall Dimension 2 Inch Width x 3 Inch Depth x 3-3/4 Inch Height- Includes 120 Volt AC Factory Installed Shunt Trip |
